WB11 Series
| Product Name | Height | Width | Thickness | Plumbing Axes Center to center | Wall to Pipe center | Wall Distance | Tube Quantity |
| mm | mm | mm | mm | mm | mm | ||
| H | W | D | C | - | - | ||
| wB11-8/450 | 800 | 450 | 46 | 400 | 67 | 96 | 8 |
| wB11-9/450 | 1000 | 450 | 46 | 400 | 67 | 96 | 9 |
| wB11-12/450 | 1200 | 450 | 46 | 400 | 67 | 96 | 12 |
| wB11-15/450 | 1600 | 450 | 46 | 400 | 67 | 96 | 15 |
| wB11-8/600 | 800 | 600 | 46 | 550 | 67 | 96 | 8 |
| wB11-9/600 | 1000 | 600 | 46 | 550 | 67 | 96 | 9 |
| wB11-12/600 | 1200 | 600 | 46 | 550 | 67 | 96 | 12 |
| wB11-15/600 | 1600 | 600 | 46 | 550 | 67 | 96 | 15 |
